Renogy 100W 12V Mono Solar Panel Kit w/ 30A PWM Charge Controller

PANEL:

Maximum Power at STC: 100W

Open-Circuit Voltage (Voc): 24.3V

Short-Circuit Current (Isc): 5.21A

Optimum Operating Voltage (Vmp): 20.4V

Optimum Operating Current (Imp): 4.91A

Maximum System Voltage: 600V DC

• CHARGE CONTROLLER:
• Nominal Voltage: 12V
• Rated Charging Current: 30A
• Max. PV Input Voltage: 25VDC
• Max Gauge Size: Up to 8AWG
• Weight: 0.65lbs / 0.29kg
• Dimensions: 6.45 x 4.31 x 1.76in /163.8 x 109.6 x 44.7mm

The Renogy 100W Solar Starter Kit is easy for you to install, and is the most economical choice for solar beginners. This Renogy Solar Kit is an ideal choice for both off-grid and mobile solar power applications.

This Solar Panel Kit will produce an average of 500Wh of electricity per day (Based on 5 hours of direct sunlight conditions). With the Wanderer Li 30A PWM Charge Controller, the kit can meet your further power needs by adding more of the same solar panels to expand up to 400W.

• What's in the box:
• 100W Monocrystalline Solar Panel
• WANDERER Li 30A Charge Controller
• Mounting Z Brackets (set of 4)
• 1 pair of 20ft 10AWG Adaptor Kit
• 1 pair of 8ft 10AWG Tray Cables

The bypass diodes ensure that the panel has an excellent performance in a low-light environment and the TPT back sheet dissipates excess heat to ensure smooth output performance. The Cell Efficiency can reach 22%.

The Wanderer PWM charge controller features advanced 4-stage charging (bulk, boost, float, and equalization) to ensure your battery is efficiently and safely charged to 100%.

The Wanderer PWM Charge Controller is compatible with four different types of batteries: Sealed, Gel, Flooded, and Lithium batteries.

By connecting the BT-1 Bluetooth module to the RS232 communication port, you can monitor the system status in real-time through the DC Home app.

Please note the BT1 Bluetooth Module is not included.

The corrosion-resistant aluminum frame with strong corner braces is designed for long-term outdoor use, giving the panels a long service life.

The IP65 Junction Box protects against environmental particles and low-pressure water jets. These IP67 waterproof solar connectors effectively prevent water and dust from entering the connector during extended outdoor use.

This Renogy Solar Kit includes all of the equipment necessary for building a new system. The included cables, Z-brackets, and pre-drilled holes on the back frame of the panel allow fast and secure mounting.
